| Products

Guangdong Shoumenshen Group Police Equipment Division united with famous universities and group research institutes to build the third generation of police high-definition audio and video law enforcement instruments. The technical parameters rank first in the same industry; the product adopts waterproof two-color mode structure technology, with wide-angle dual HD (actual pixels up to 20 million), camera status can be photographed; ultra-long-night vision, long standby, scalable GPS positioning , 3G transmission and other functions. Widely used in: armed police, public security, justice, military, urban management, transportation, industry and commerce and other law enforcement departments.

| Features

◆Two-color molding process

Appearance Mechanical Structure:

The body is designed with a two-color mold process, and the button and the protruding part are overmolded and integrated into the casing. The degree of protection of the enclosure complies with the IP67 standard of GB4208-2008. The dustproof level is 6 and the waterproof level is 7th. The function design adopts one-button operation design and corresponding indicator light, which can enter video, camera, recording, playback, intercom and other functions.

◆wide-angle lens 135 degrees

Photosensitive device wide angle:

1/2.5° ColorCMOS sensor 16 megapixel camera, macro editing 1-8 times lens, can be close.

The internal and external cameras are 135 degrees, bringing a new high-definition view and undistorted images.

◆Photography:

16 million pixels, 4608*3456 resolution, showing more details, automatically adjusting white balance and sensitization, clear image, providing a reliable basis for research and development. High-speed continuous shooting function, fast reading and capturing every moment, in every fierce and moving scene can capture clear and intact important photos, fully meet the requirements of snapping and retaining important evidence.

◆Internal and external video recording function:

Real-time shooting of high-definition video quality audio recording, built-in camera HD video resolution can reach 1920*10801440*10801280*720848*480 multi-level adjustable, external HD camera: Video resolution 1920*1080, 1440*1080, 1280*720, 848*480 recording frame rate ≥ 60 frames/second.

◆Recording:

With dual-microphone noise reduction technology, the sound is clearer and brighter. Support for simultaneous audio recording, or separate recording.

◆ walkie-talkie microphone:

Integrated microphone function, linked to the walkie-talkie via a dedicated cable, as a "shoulder microphone", bringing clear and loud language quality, ensuring users stay in noisy environments Unobstructed intercom, working independently with the imaging system, does not affect each other. Even if the law enforcement recorder is exhausted, it will not affect the work of the microphone.

◆Day and Night Switching and Infrared:

Using a dual filter switching device, the law enforcement recorder can switch between infrared and day and night modes to ensure no color cast during daylight. You can set the manual or auto cut to activate the sensitization function. Feelings 10 meters away from the facial expressions of the person, 20 meters away from the contours of the human body.

◆Battery Capacity:

The battery has an integrated design with built-in battery and a battery capacity of 3500MAH. It can reach standby for 50 hours without an external battery, and the continuous recording time can reach 10 hours.

◆Visual Remote:

Using a 2-inch color HD display visual wireless remote control, remote control for boot, video, photo, recording, playback and other functions.

◆Data Interface Type:

High-speed USB2.0/HDMI/IP〇D-30P interface HD input and output.

◆Character Overlay and Timing:

Device-generated video or photo files are required to have a date and time-to-second display, and the user ID number can be overlaid. The system system time cannot be modified by the machine. After connecting with the computer, the management software automatically checks the time with the computer.

◆Video file segmentation:

The body design is: the video is automatically saved once every 20 minutes, automatically named after the video system time (format: year, month, day, hour, minute, second) This makes it easy to find and manage people.

◆ Fixture:

Use direction dynamic fixture, with front, back, left and right adjustments, you can adjust the shooting angle.

◆Storage Media:

The built-in memory comes standard with 16GB and supports 32G expansion.

◆Data Security Management:

The law enforcement recorder itself can only view and play back law enforcement videos, photos, recordings, cannot be deleted and modified, and can only be copied after connecting to the computer via a password and a dedicated data cable. , modify or delete.

◆Unlimited Transfer:

Optional expansion of 3G equipment, real-time operation and monitoring of unlimited transmission of sweet potato live animation to PC.

◆Targeting:

Can expand the global positioning GPS, Beidou chip, can play back the law enforcement recorder track through the map.

◆Playback:

2-64 times fast forward and rewind

◆List View Sound Playback:

This unit supports playback of photos and video files, and video files can play sounds on this unit. Built-in walkie-talkie speaker, the machine outputs the sound synchronously during playback of the camera, and there is an audible prompt when the phone is turned on and the battery is low.

◆Power Saver Mode:

Automatically closes after three minutes after booting up or during recording. You can manually enter the power save mode by pressing the power button.

◆Log function:

The boot automatically generates a usage log, which records the switch machine and the camera time. (Note: Model DSJ-6S law enforcement instrument has been selected as "Special Product Catalogue for Inspection of Audio and Video Recorders by the Police Department of the Ministry of Public Security")
